Custom AN4 PTFE Braided Turbo Oil Coolant Hose Lines

AU$69.98 AU$63.62
  • HEL Official 1 Year Warranty
    Official Warranty
AU$69.98 AU$63.62
In Stock
Quantity
Description

With our custom -4 AN braided PTFE hoses, you can have professional-grade hoses tailored to your exact specifications designed for rigorous motorsport use.

We use stainless steel fittings that are swaged directly to high-performance braided hose, with a reinforced PTFE inner for added strength. The inner PTFE hose is then wrapped in layers of braided stainless steel, providing further reinforcement, and a protective wipe-clean PVC coating can be added for additional durability. If you plan on running the hose close to a direct heat source without heatsleeve, we suggest selecting uncoated hose.

Before dispatch, each custom hose undergoes a quality inspection to ensure that it meets our high standards, and arrives ready to fit to your latest project.

Applications

Turbo oil and water feed and return lines, pedal box hoses and more.

Specifications
Hose inner material PTFE
Hose outer material Stainless steel (303/304) and optional protective PVC cover
Fittings material Stainless steel (303/304)
Inside diameter 6.35mm (1/4 inch)
Outside diameter 13.0mm (0.51 inch)
Maximum working pressure 400 PSI (2.75 MPa)
Burst pressure 1600 PSI (11.03 MPa)
Minimum bend radius 63mm (2.48 inch)
Hose weight 225 grams/m
